Cable 8723 2 Pair Belden Equivalent LSZH

Cable 8723 2 Pair Belden Equivalent LSZH is a two-pair, individually screened cable for signal and control wiring. It is a Belden 8723 equivalent, made for runs where interference from nearby equipment could affect the signal.

What the specs mean in practice

• 2 pairs: four conductors in total, enough for two separate signal or control circuits.
• 22 AWG (American Wire Gauge), tinned stranded copper: stranded conductors are more flexible than solid ones, and the tin coating is applied to the copper.
• Aluminium-Mylar screen: each pair is screened individually, which helps limit interference between pairs and from outside sources.
• LSZH (Low Smoke Zero Halogen) outer sheath: the jacket is listed as LSOH. It is chosen where low smoke and no halogens matter.

Suitable applications

• Low voltage analogue signals, such as 4-20mA and 0-10V
• Low voltage digital control, such as 24V
• Line level audio
• Computer communication
• Panel wiring

Before you order

Check that your equipment's terminals suit 22 AWG conductors. Decide how many separate circuits you need, as each pair carries one. For anything beyond the applications above, confirm the cable suits the signal type and voltage first.
