What's in the box
Every part in this kit and how many of each you get. Tap a part to see its full specification.
5 cameras included, keeps about 7 days of footage, uses analogue cameras; check existing coax cable condition and compatibility before reuse.
Recorder capacity
5 included cameras use 5 of the recorder’s 8 channels. 3 channels remain for expansion. Before adding cameras, check supported resolution, recording bandwidth and available power or PoE ports.
Recording storage
2TB storage is included. Estimated recording time: about 7 days with continuous H.265 recording. The estimate uses 2 Mbps per camera up to 2MP, 4 Mbps up to 5MP and 8 Mbps above 5MP, summed for mixed camera models. Actual retention depends on settings, scene activity and usable drive capacity; motion-only recording varies with activity.
Before installation
Check the component list below for included cables, power supplies and mounting accessories. Choose cable lengths and camera positions for your layout; camera count alone does not establish coverage. Confirm lens field of view, lighting and weather protection for each position.
The recorder
Hikvision 8-ch 8MP 1U H.265 AcuSense DVR
The box that saves everything and runs the app
The cameras× 4
Hikvision 3K Two Way Audio Fixed Turret
What goes on the wall
The cameras
HIKVISION 4K Two Way Audio Fixed Turret
What goes on the wall
The hard drive
2TB - HDD 3.5" SATA Hard Drives – Free Installation with Any CCTV Kit or Package -Ideal for 24/7 continuous recording
Where the footage is kept
The power supply
12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed
One plug that powers the cameras
The cable× 5
RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
Runs from each camera back to the recorder
Want different cameras, a bigger drive or longer cable runs? Open this exact kit in the builder and change any part — everything is re-checked against the rest as you go, so you cannot end up with parts that do not work together.
Product Description
A complete 8-channel HD-over-coax CCTV kit built on the Hikvision IDS-7208HUHI-M1/E + 4× Hikvision DS-2CE78K0T-LTS + 1× Hikvision DS-2CE78U0T-LTS-Black. 5 cameras at 5MP + 4K (8MP) — sized for a shop or small office. The included 2TB hard drive holds about 7 days of continuous recording — the estimate assumes recording all 5 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when the drive fills. Power and cabling are covered: 5× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR, 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed. Nothing else is needed to start recording: recorder, cameras, storage, power and cabling are all in the box. In the box: 1× Hikvision 8-ch 8MP 1U H.265 AcuSense DVR; 4× Hikvision 3K Two Way Audio Fixed Turret; 1× HIKVISION 4K Two Way Audio Fixed Turret; 1× 2TB - HDD 3.5" SATA Hard Drives – Free Installation with Any CCTV Kit or Package -Ideal for 24/7 continuous recording; 5× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed. Free Hik-Connect app (iOS / Android) for live view and playback.
Specifications
- System type
- Analog (HD over coax)
- Built on
- Hikvision IDS-7208HUHI-M1/E + 4× Hikvision DS-2CE78K0T-LTS + 1× Hikvision DS-2CE78U0T-LTS-Black
- Recorder
- 8-channel Hikvision 8-ch 8MP 1U H.265 AcuSense DVR
- Cameras included
- 4× Hikvision 3K Two Way Audio Fixed Turret; 1× HIKVISION 4K Two Way Audio Fixed Turret
- Camera resolution
- 5MP + 4K (8MP)
- Storage
- 2TB HDD — about 7 days of footage, recording all 5 cameras continuously at high quality (H.265) — the load is 4× 5MP + 1× 8MP
- Cables & PSU included
- 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed; 5× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
- What you need to add
- Nothing — recorder, cameras, hard drive, power and cabling are all included
- Mobile app
- Free Hik-Connect app (iOS / Android) for live view and playback
- What's in the box
- 1× Hikvision 8-ch 8MP 1U H.265 AcuSense DVR; 4× Hikvision 3K Two Way Audio Fixed Turret; 1× HIKVISION 4K Two Way Audio Fixed Turret; 1× 2TB - HDD 3.5" SATA Hard Drives – Free Installation with Any CCTV Kit or Package -Ideal for 24/7 continuous recording; 5× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed
