Product Description
The HDMI Cable 4K High Speed 1.5m 60Hz Ethernet HDMI-A Male to Male Black (SKU HDMI-CABLE-4K-1.5M) links an NVR (network video recorder) HDMI output to a monitor. At 1.5m, it suits a recorder and screen that sit close together, so no booster is needed.
What each spec means on screen
| Spec | What you get |
|---|---|
| HDMI 2.0 Premium High Speed, 18Gbps | 4K at 60Hz (3840x2160) with 4:4:4 chroma, meaning full colour sampling |
| HDR support | HDR10 (high dynamic range) pictures and multi-channel audio |
| Triple shielding (foil + braid), 30-34AWG OFC copper | Rejects interference from rack PSUs, Ethernet and DC leads |
| Gold-plated contacts | Low-loss connection at each end |
| HDMI 1.4 backward compatibility | 1080p at 120Hz from older sources |
| HDCP 2.2, ARC, CEC, Ethernet channel | Content protection, audio return, power sync between devices, and a control data channel |
OFC is oxygen-free copper. ARC is audio return channel. CEC is consumer electronics control. HDCP is High-bandwidth Digital Content Protection.
What else you need
The cable carries the signal. It does not create it. To see 4K at 60Hz, the NVR must output that resolution and the monitor must be a 4K (UHD) model.
Build
The PVC jacket is 4.5-6mm OD (outer diameter) with moulded strain relief. It is flexible enough for cable trays alongside Cat5e and DC pigtails. It is RoHS compliant and tested for 10,000+ mating cycles.
Specifications
- Product Type
- 4K High Speed HDMI Cable
- Connector Type A
- HDMI Type A Male (19-pin)
- Cable Length
- 1.5
- HDMI Version
- 2.0 Premium High Speed
- Max Resolution
- 4K (3840x2160) @60Hz
- Bandwidth
- 18 Gbps
- Shielding
- Triple (Foil + Braid)
- Conductor Material
- Oxygen-Free Copper (OFC)
- Wire Gauge
- 30-34 AWG
- Diameter
- 4.5-6
- Contacts
- Gold-plated
- Supported Features
- ARC, CEC, HDCP 2.2, Ethernet, HDR
- Colour
- Black
Frequently Asked Questions
Does this cable carry 4K at 60Hz?
Yes. It is HDMI 2.0 Premium High Speed certified with 18Gbps bandwidth, giving 3840x2160 at 60Hz with 4:4:4 chroma.
Will it work with an older 1080p source?
Yes. It is backward compatible with HDMI 1.4 and handles 1080p at 120Hz.
Do I need a booster at 1.5m?
No. The 1.5m length is intended for rack-to-console runs without a booster.
Will it cope with interference in a rack?
It has triple shielding (foil and braid) to reject interference from rack Ethernet, power supplies and DC leads.
