Product Description
The 8 Port Lever Wire Connector Terminal Block for CCTV Power Distribution (SKU 8-WAY-TERMINAL-BLOCK-GREY) joins or splits low-voltage copper wiring in one insulated block.
What the specs mean on site
- 8 ports: up to eight conductors meet in one place, so a single power feed can be shared out to several cameras from one point.
- Lever clamp: lift the lever, insert the conductor, close it. No crimping tool and no screwdriver.
- Solid and stranded copper: suits CCTV power cable, alarm wiring and low-voltage control wiring.
- Reusable: open the lever to release a conductor, then refit it during maintenance, cable extensions or system upgrades.
- Compact insulated housing: small enough for CCTV junction boxes, network cabinets and structured wiring enclosures.
Where it fits
It distributes 12V DC or 24V DC power (DC means direct current) from a central power supply to multiple cameras. That keeps an enclosure organised, with clean lever connections instead of twisted joints.
What else you need
- A power supply that matches your cameras' voltage.
- Copper conductors for each camera run.
- A junction box or cabinet to house the block.
Add up the cameras' load and compare it with the power supply's rating before you wire the block in.
Frequently Asked Questions
Do I need tools to connect wires?
No crimping tool or screwdriver is needed. You open the lever, insert the conductor and close the lever.
Can it take stranded cable?
Yes. It suits both solid and stranded copper conductors.
Which voltages is it meant for?
It is intended for 12V DC or 24V DC CCTV power distribution and low-voltage wiring.
Can I reuse it after removing a wire?
Yes. The lever design lets you remove and refit conductors during maintenance or upgrades.
