SPL-2-8 Clear Lever Wire Connector 2 In 8 Out Splicing Terminal

Ten wire ports in one clear block: two inputs, eight outputs. The Lever Wire Splicing Terminal 2 In 8 Out, Clear Housing (SKU SPL-2-8-2-CL) joins conductors without a screwdriver or crimping tool.

What each spec means in use

• 2 input and 8 output terminals: wiring from the input side is distributed to up to eight outgoing conductors from a single block.
• Lever-lock clamping: lift the lever, push in the stripped wire, press the lever down. The wire is held without tools.
• Transparent housing: you can see whether each conductor has gone fully in before the junction box or panel is closed.
• Solid, stranded and flexible conductors: all three wire constructions are accepted, so you do not need a different connector for each.
• Reusable: lift a lever to release the wire, then rewire when the circuit changes.
• Metal internal contacts, insulated housing: the contacts carry the connection, and the outer body is insulated.

What you need to supply

Only the cable. Strip each conductor before inserting it. The connector is compact, so it suits junction boxes and electrical panels where several cables meet.

Typical jobs

Lighting circuits, electrical distribution wiring and control panels, where one feed has to branch to several runs.
