SPL-2-6 Clear Lever Wire Connector 2 In 6 Out Splicing Terminal

The Clear Lever Wire Connector, 2 In 6 Out Splicing Terminal (SKU SPL-2-6-2-CL, also written SPL-2-6) takes incoming wiring on 2 input ports and passes it to 6 output ports. One source can feed several conductors from a single body.

What each spec means in practice

• 2 input ports: the supply or signal wiring goes in here.
• 6 output ports: six conductors leave the connector, so one feed reaches several runs.
• Lever lock: lift the lever, insert the stripped wire, press the lever down. No screwdriver, crimping tool or soldering is needed.
• Transparent housing: you can see whether each wire has gone in fully before you close up.
• Solid, stranded and flexible conductors: all three types are suitable.
• Reusable: release the lever to change the wiring later.
• Insulated plastic housing with metal contacts: stable conductivity, with protection against short circuits.

What else you need

You need stripped conductors and somewhere to mount the connector. The compact design is made for junction boxes, lighting fixtures, electrical cabinets and control panels. Typical jobs are lighting circuits and electrical distribution wiring, where one point supplies several wires.
